Niche 1PC NC277 CALABRIA 5 5-Lug Gloss Black Machined Wheels

Back to Results

Niche 1PC NC277 CALABRIA 5 — Gloss Black Machined

Finding wheels that fit your vehicle

Fits your vehicle · Bolt — · Hub — Change Vehicle

FREESHIPPING

FITMENTGUARANTEED

PRO INSTALLAVAILABLE

Per wheel —

Set of 4 —

Ways to pay

Quantity

Call to check availability

Installed by Road Runner Wheels & Tires — family-owned in Marietta since 2010. Questions? Call (678) 400-6467.

About This Wheel

Pick up the Calabria 5 and the first thing you notice is how the spokes taper — they start broad at the hub and carve inward toward the lip, giving the face real depth without looking busy. The machined cuts catch light in a way that shifts with the viewing angle, so the wheel reads differently under a parking lot fluorescent than it does in direct sun. That contrast between the gloss black spoke faces and the machined surfaces is what makes it work on darker vehicles — charcoal, midnight blue, or white all let the wheel do the talking. Sedans and crossovers in the 5x114.3 family are where this wheel lands most naturally, though fitment ultimately depends on your specific year and model.

Specifications

Diameter x Width	20" x 10.5"
Bolt Pattern	5x114.3
Offset	ET+40mm
Backspacing	7.32"
Hub Bore	72.56mm
Load Rating	1800 lbs
Construction	Cast
Material	Aluminum alloy
Finish	GLOSS BLACK MACHINED
Manufacturer Part Number	NC277BD20051240

Build Your Package

Add Matching Tires

Brand Tire size Sort by

Loading matching tires from our catalog…

How it works

1 Call 678-400-6467 to confirm fitment & availability
2 Apply above or choose your financing option at checkout
3 Get approved instantly — no delay

678-400-6467 · Marietta, GA · Hablamos Español

Fitment

This wheel runs the 5x114.3 bolt pattern, which covers a range of half-ton trucks and SUVs depending on hub bore and offset. ET+40mm offset is typical for stock-height fitments; leveled and lifted trucks may want different offset/backspacing combinations to clear larger tires. A hub-centric ring is recommended when the wheel hub bore is larger than the vehicle hub.

About the GLOSS BLACK MACHINED Finish

Niche is a Wheel Pros brand that has been producing cast and flow-formed aftermarket wheels for street and light truck applications for well over a decade. Their one-piece cast lineup is positioned as an accessible entry point into the Niche catalog — consistent quality control, solid finish durability, and a wide range of fitments. They're not a boutique forged house, but for cast wheels in this price tier, the construction and cosmetic consistency hold up.

About Niche 1PC

Niche 1PC produces wheels distributed nationally through trusted vendor channels. Catalogs are stocked, MAP-pricing is enforced, and warranty coverage is honored at the manufacturer level.

Installing at Road Runner Wheels & Tires

Mount and balance is same-day in most cases in our shop. We program TPMS sensors on-site and pair wheels with matching tires when needed. Same shop handles lift kits, suspension work, and full builds.

Questions We Get

Will this fit my truck or SUV?

A 20x10.5 at 40mm offset in 5x114.3 is a common fitment for many sport trucks and SUVs, but width and offset together determine whether you'll need a spacer, have rubbing issues, or clear the brake caliper. Always verify your vehicle's hub bore, load rating requirements, and backspacing before ordering — we can cross-check that for you if you reach out with your year, make, and model.

Do lug nuts come included?

No, lug nuts are sold separately. The seat type — conical, ball, or flat — has to match both your vehicle's lug nut seat and the wheel's lug seat, so it's worth confirming before you order. We stock a range of compatible hardware and can point you toward the right spec for this wheel.

Fitment specs: the Niche 1PC NC277 CALABRIA 5 comes in 5x114.3 bolt pattern, ET+40 offset, 7.32" backspacing, 72.56mm hub bore, a 1800 lbs load rating.
