About This Wheel
Pick up the XD869 R.O.F. and the first thing you notice is the weight distribution — it's a cast wheel, but KMC's tooling keeps it honest. The face runs a multi-spoke pattern with deep pocketing between the spokes, which gives the profile real depth rather than a flat, printed-on look. In flat black, the recesses go dark and the spoke faces hold just enough sheen to read as dimensional under direct light. That contrast works especially well against olive drab, military green, or slate gray body colors. White and silver Jeeps look sharp with it too. The -18 offset pushes the face outboard, so when it's mounted, the wheel fills the fender correctly rather than sitting recessed and looking like an afterthought.
Specifications
| Diameter x Width | 20" x 10" |
|---|---|
| Bolt Pattern | 5x127 / 5x139.7 |
| Offset | ET-18mm |
| Backspacing | 4.79" |
| Hub Bore | 78.10mm |
| Load Rating | 2650 lbs |
| Construction | Cast |
| Material | Aluminum alloy |
| Finish | BLACK |
| Manufacturer Part Number | XD869MX20103518N |
Build Your Package
Add Matching Tires
Recommended tires for your — wheels on your vehicle
Loading matching tires from our catalog…
How it works
- 1 Call 678-400-6467 to confirm fitment & availability
- 2 Apply above or choose your financing option at checkout
- 3 Get approved instantly — no delay
Fitment
This wheel runs the 5x127 bolt pattern, which covers a range of half-ton trucks and SUVs depending on hub bore and offset. ET-18mm offset is typical for stock-height fitments; leveled and lifted trucks may want different offset/backspacing combinations to clear larger tires. A hub-centric ring is recommended when the wheel hub bore is larger than the vehicle hub.
About the BLACK Finish
XD Series is a sub-brand under KMC Wheels, which has been producing aftermarket wheels since the mid-1990s. XD specifically targets the truck and off-road segment, and the lineup is engineered and load-rated with that use case in mind. The brand has broad fitment coverage and consistent quality control across its cast offerings, which is why it stays a reliable choice at this price point.
About XD
XD produces wheels distributed nationally through trusted vendor channels. Catalogs are stocked, MAP-pricing is enforced, and warranty coverage is honored at the manufacturer level.
Installing at Road Runner Wheels & Tires
Mount and balance is same-day in most cases in our shop. We program TPMS sensors on-site and pair wheels with matching tires when needed. Same shop handles lift kits, suspension work, and full builds.
Questions We Get
Will this fit my truck?
This wheel is drilled in a 5x127 bolt pattern with a -18mm offset, which is a direct match for Jeep Wrangler JL and JK models, among others. That said, always cross-reference your specific year and trim against confirmed fitment data — hub bore, brake caliper clearance, and suspension lift all factor into whether a wheel works without modification.
Do lug nuts come included?
Lug nuts are not included with this wheel. XD wheels typically require a conical seat lug nut in the correct thread pitch for your vehicle — most Jeep applications use a 14x1.5 thread. We stock compatible hardware and can confirm the right spec when you order.
Fitment specs: the XD XD869 R.O.F. comes in 5x127 bolt pattern, ET-18 offset, 4.79" backspacing, 78.10mm hub bore, a 2650 lbs load rating.
